Performance and Processing Power
The RS5100 offers fast, point-and-shoot performance through two scan engine options: the SE4710 for standard range scanning and the SE4770 for extended range and greater depth of field. Both engines use PRZM Intelligent Imaging, delivering near-instant capture of even damaged or poorly printed 1D/2D barcodes.
Display and Input Design
There’s no screen, but the RS5100 includes:
-
Four programmable RGB status LEDs for scan and battery status
-
Manual ambidextrous trigger (single, double, or top-mounted options)
-
Modular trigger assemblies that can be swapped for hygiene and comfort
It supports left or right hand use and offers five wearing styles including:
Connectivity and Expansion
The RS5100 connects wirelessly via Bluetooth (v4.0 or v5.2 depending on model) to any compatible host device:
Tap-to-pair is supported via NFC, eliminating complex setup.
Battery Life and Charging
Two removable battery options:
-
Standard battery – 480 mAh (12+ hours, 14,400 scans)
-
Extended battery – 735 mAh (longer shifts, freezer-rated)
Charge via:
Hot-swappable design keeps the RS5100 active during long shifts
Security and Data Protection
The RS5100 does not store data directly. Security is managed through its host device, but Zebra’s PowerPrecision+ battery tools help IT monitor battery health and usage across the fleet.
Usability
Weighing just 70g, the RS5100 is ideal for:
-
Warehousing & Logistics – picking, packing, sortation
-
Retail Operations – in-store inventory, markdowns, order prep
-
Transportation – loading/unloading, route verification
-
Manufacturing & Field Service – component tracking, route accounting
Its rugged build allows flexible deployment across departments or job roles.
Watch the video below to explore how the Zebra RS5100 delivers performance, portability, and enterprise-ready features in one powerful device.
Rugged Durability
The RS5100 is IP65 sealed and survives:
-
Drops: Multiple 1.8 m drops to concrete
-
Tumbles: 1,000 tumbles from 0.5 m
-
Temperature: Operates from -20°C to +50°C
It withstands vibration, ESD, and high-pressure hose-downs. All critical components — battery, trigger, and housing — are field replaceable.
Support & Availability
For all products supplied by Roaming Technologies our extended warranty support comes at no charge for the lifetime of the device. This means we'll be your single point of contact to assist in any warranty or repair issues, ensuring your device gets back into the field as quickly as possible.
Shipping costs and delivery lead times will vary depending on the product options and order quantities required. With the use of Australia-wide distribution centres, drop shipments direct from vendors and overnight shipping, we offer industry leading product availability.
If you have any questions about the Zebra RS5100, feel free to call us at 1300 131 933 and speak with one of our specialists, or contact us online for assistance.
